1229-27 - AIR INTAKE CAP - $65Note that original Air Caps were always made of cast steel. NEVER aluminum, bronze or mystery metal.Made from an NOS part. Nickle plated. Cast steel, open backed, 3 1/4" diameter. 1927-1931 Harley-Davidson Twins.
.jpg "image title")
.jpg "image title")
1238-24 - DL10 THROTTLE SHAFT LEVER - $55, nickel platedHarley-Davidson, Linkert & Schebler, 1924 to 1933 - 61" & 74" Twins. 1930 to 1933 DLD & RLD, later 1933 to 1935 - 45" Twins.
.jpg "image title")
.jpg "image title")
.jpg "image title")
065 - SHIFT TOWER FRAME BRACKET CAP BOLT, $6.00 each, 2 usedSpecial bolt with a 3/8" hex head. 5/16" x 24 tpi bolts with 1/2" or 7/16" hex heads (later versions of the 065 bolt) will not fit. Exclusive to me. Heat treated 4140 Chromoly to Rockwell 40C.
1915-1929, Twins.
.jpg "image title")
.jpg "image title")
2410-14 - CLUTCH PEDAL HINGED TOE PIECE - $30 Parkerized. Each part is fitted to an
original clutch pedal."IMPORTANT!" Heat Treated 4140 Chromoly to Rockwell 40C. 1914-1929 Big Twins.
.jpg "image title")
2653-29 EARS - FRONT FORK TRIPLE CLAMP EARS- 1929 - $40 per setIf you have an original 1929 Triple Tree with broken headlight ears, this is for you.
Ears are easily welded to the original tree using 7018 or stainless rod after pre-heating the parts.1929 - 74" Twins.
.jpg "image title")
2934-25B - JD RIGHT FOOTBOARD SIDEBAR BRAKE SPRING TAB
with rivet - $121925-1929 61" and 74" Twins.Tab is Carbonitride to a depth of 0.030" to 0.060" and Heat treated A1011 to RH 30-35.
.jpg "image title")
3101-25 SEAT BAR BRACKET - $45Note NE-30 raised digits. These are a little short because of casting shrinkage. Make sure it sits at least 1/8" higher than the gas tanks. This allows the Seat T bolt to clear.
Harley-Davidson, 1925-1936, 74" & 80" Twins.
.jpg "image title")
.jpg "image title")
3103-29 - UPPER SEAT BAR PLATE (6 hole shown, or 4 hole)- $183103-29S - LOWER SEAT BAR PLATE- $10Spring steel plates for the rear cross bar, 0.125" thick. Black color results from the heat treating process.
Easily removed by blasting. 1929-1964, Big Twins & 45".
.jpg "image title")
.jpg "image title")
4054-23 - REAR WHEEL BRAKE LEVER- $801923-1929, J & JD Big Twins.Heat Treated 4140 Chromoly Steel to Rockwell 40C.
.jpg "image title")
.jpg "image title")
.jpg "image title")
4521-26 - SWITCH KEY, BERYLLIUM-COPPER SPRING ALLOY, Cadmium Plated - $20/pair, price reduction, I made too many.These are exclusive to me. No one else has ever made these since Harley stopped. Exact dimensions as OEM parts. Don't settle for poorly made steel reproductions. These are made from BERYLLIUM-COPPER SPRING ALLOY. Key Tang has same 0.040" bends as originals and the heat treating keeps it that way so the keys won't fall out when riding. Tie the keys together with a leather string, just the same.1926-1936 All Models. Vacuum Precipitation Hardened to Rockwell 40C.
.jpg "image title")
4859-29 - RIGHT HORN BRACKET- $554860-29 - LEFT HORN BRACKET- $55Brackets will need to be fitted. 1929 61" & 74".
.jpg "image title")
11331-X - Out of production, out of stock. Select spare parts shown.No more cast Brackets or Jiffy Legs. Fits 1923 to 1929 - 61" & 74" TwinsAvailable (see part descriptions below): 13205X Leg Stop $15, 13203X Spring Collar $14, plus the nut.
.jpg "image title")
13203X - SPRING COLLAR- $141923-1929 61" & 74".
.jpg "image title")
13205X - LEG STOP- $15Heat treated to Rockwell 30C. 1923-1929 61" & 74".
.jpg "image title")
.jpg "image title")
.jpg "image title")
11780-34 - DICE KEYS - $60 with longer leather and Handlebar Clip.1926-1936 All Models except EL.Red, Green, and White antique Bakelite Dice, Dice made in the 1940's and 1950's, with my exclusive heat treated berylillium-copper keys, braided leather strap that runs through a brass tube in each die, and crimped brass rings to tie each end. Each key is glued into a milled 0.400" wide slot. Only available with a 6 and a 5, as per the originals.Dice Keys were originally introduced by Harley-Davidson in 1933. Above drawing is from the 1934 Accessory Catalog. There have been many manufacturers of Dice Keys thoughout the years but all (to my knowledge) have used modern plastic dice and poorly made steel keys.
.jpg "image title")
314011M - Handlebar Clip - $10.Use with above Dice Keys (1 already supplied), if you need an extra Clip. Unless keys are firmly inserted into the switch, they will vibrate out. Ever wonder why originals are so very rare? This clip will keep them from becoming lost on the roadside.
Only one needed per set of Dice Keys.
.jpg "image title")
.jpg "image title")
AIRHORN LINKERT -
NICKEL PLATED STEEL - $65Open backed, 2 3/4" X 4". All letters in relief. Offered by Linkert in the 1930's and 1940's. Made in the USA.
